Outdoor Advertising Tri-vision Aluminium Alloy Billboard

FOB Reference Price:Get Latest Price
US $100-200 / Square Meters | 1 Square Meter/Square Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
FIRST
Model Number:
F3V-131
Panel meterial:
Transparent Tempered Glass
color:
white or customized
suit occation:
outdoor
image:
depend on the height of the trivision
size:
customize
flipping performance:
only one type can be set,base on customers' requirement
Certification:
CE, Rosh, ISO, SGS
Wind resistance:
10 class
Controlling system:
Siemens LOGO
5.Weight:
20kg/square meter
SupplyAbility
SupplyAbility:
10000 Square Meter/Square Meters per Month
Packaging & Delivery
Packaging Details
cardboard
Port
shenzhen
Lead Time :
10 working days
Product description

1.specification



1. Primary Material Environmental aluminum alloy of special quality
2. Drivingdouble-gear steps driving system
3. Specification of external frame145mm (width) * 160mm (thickness)
4. Width of triangle prism 131mm,thickness1.35-2.00mm
5. Weight 20kg/square meter
6. Image Gap6-8mm
7. Image combinationtriangular prism 8m without joint and no length limit
8. Image flipping timeeach face 6-12 seconds (preset )
9. Controlling systemSiemens LOGO
10. Image stop timefreely set from 0-900 seconds
11. Power supplyvoltage 220v, current 0.54A, frequency 50HZ, power 90W
12. Motor90W original Panasonic motor
13. Wind resistance10 class
14. Operation service life

qualified installation will ensure normal service life up to 10 years

      based on 16 hours each day

15. Flipping performance   A. Simultaneous  B. Wave type  C. Curtain opening type
   D. Curtain closing type E. Flipping step by step.  F. Flipping from part to part.
16. AvailableT pattern pole, upper building ads, outside building ads, intersection



2.Advantage

  1. The main material is made of Special Environmental aluminum alloy with high quality.
  2. The plastic parts are made of Special American “Dupont” engineering plastic(self-lubrication).
  3. The double gear stepping wheel(gear) can be knocked off / detachable and adjusted easily

3.Application



Airport, station, catering industry, entertainment industry, medical institution, golf course, supermarket, exhibition, stadium and gymnasium, financial industry, organ and enterprise, building adverting and billboard advertising, subway, hotel, rail way station, bus station, lift, bank, Commercial center, wedding photograph, large exhibition, mobile show, chain-store, restaurant, fast-food canteen...
